LCD Graphic Display Module

AZ Displays offers the below standard sizes. In addition, we are equipped to manufacture to¬†customers’ custom needs and designs. We have a full service engineering department to help¬†develop new graphic LCD modules and reverse engineer existing projects.

Jump to:

95 x 896 x 24100 x 160100 x 64100 x 32106 x 56122 x 32128 x 64128 x 128160 x 96240 x 128240 x 64320 x 240480 x 256480 x 320640 x 480
95 X 8 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
AGM9508A
Download AGM9508A PDF70.1 x 29.97 x 15.0 58.0 x 10.8 0.50 x 0.55 0.55 x 0.60 -20~+70ST75225.0V/3.3V
96 X 24 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
AGM9624A
CGDownload AGM9624A PDF27.0 x 17.7 x 1.7 24.09 x 8.26 0.19 x 0.195 0.22 x 0.22 -20~+70NT75343.3V
100 X 160 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
AQM1016A
Download AQM1016A PDF43.5 x 57.0 x 8.7 32.0 x 50.0 0.275 x 0.275 0.29 x 0.29 -10~+60ST75283.0V
100 X 64 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
AQM1064A
Download AQM1064A PDF48 x 40 x 2.1 44 x 27 0.33 x 0.33 0.36 x 0.36 -10~+50NT7534H-BDT3.0V
100 X 32 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
AGM1032A
Download AGM1032A PDF65.0 x 28.4 x 8.0 47.0 x 18.4 0.41 x 0.45 0.44 x 0.48 0~+50PT65205.0V/3.3V
106 X 56 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
AQM1056B
CGDownload AQM1056B PDFDownload AQM1056B DRAWING36.6 x 28.0 x 9.5 32.6 x 17.6 0.27 x 0.27 0.29 x 0.29 -20~+70ST7565P5.0V/3.3V
122 X 32 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
> AGM1232E
Download AGM1232E PDFDownload AGM1232E DRAWING66.1 x 27.3 x 8.5 60.5 x 18.5 0.40 x 0.45 0.44 x 0.49 -20~+70SED15205.0V/3.3V
> AGM1232G
Download AGM1232G PDFDownload AGM1232G DRAWING84.0 x 44.0 x 9.0/13.0 for LED Backlight60.0 x 18.0 0.40 x 0.45 0.44 x 0.49 -20~+70SED15205.0V/3.3V
128 X 64 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
AGM1264B
Download AGM1264B PDF93.0 x 70.0 x 8.5
93.0 x 70.0 x 14.0 for LED BL
70.7 x 38.8 0.48 x 0.48 0.52 x 0.52 -20~+70KS01085.0V/3.3V
AQM1264C
TPDownload AQM1264C PDFDownload AQM1264C DRAWING93.7 x 52.6 x 6.8 70.7 x 38.8 0.50 x 0.50 0.52 x 0.52 -20~+70NT7538H3.3V
AGM1264F
Download AGM1264F PDFDownload AGM1264F DRAWING93.0 x 70.0 x 9.5
93.0 x 70.0 x 14.0 for LED Backlight
70.7 x 38.8 0.48 x 0.48 0.52 x 0.52 -20~+70KS0108B5.0V/3.3V
AQM1264J
CGDownload AQM1264J PDFDownload AQM1264J DRAWING79.2 x 52.6 x 5.45 70.7 x 38.8 0.50 x 0.50 0.52 x 0.52 -20~+70NT7538H3.3V
AGM1264P
CGDownload AGM1264P PDF89.7 X 49.8 X 6.0 66.8 X 35.5 0.48 X 0.48 0.50 x 0.50 -20~+70S1D156055.0V/3.3V
AQM1264PA
CGDownload AQM1264PA PDF89.7 X 49.8 X 6.7 66.8 X 35.5 0.48 X 0.48 0.50 x 0.50 -20~+70ST7565P3.0V
AGM1264R
CGDownload AGM1264R PDF72.0 x 50.4 x 6.2 66.4 x 39.4 0.45 x 0.53 0.46 x 0.54 -20~+70-5.0V/3.3V
128 X 128 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
AGM1212I
Download AGM1212I PDFDownload AGM1212I DRAWING92.0 x 106.0 x 14.5 73.0 x 73.0 0.50 x 0.50 0.55 x 0.55 -20~+70T6963C5.0V/3.3V
AQM1212K
Download AQM1212K PDF76.04 x 77.34 x 10.07 58.48 x 58.48 0.38 x 0.38 0.41 x 0.41 -20~+70ST75415.0V/3.3V
160 X 96 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
AQM1696A
CGDownload AQM1696A PDF98.48 x 67.79 x 9.2 74.31 x 44.87 0.40 x 0.38 0.43 x 0.41 -20~+70NT7538H3.0V
240 X 128 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
ATM2412B
TFTDownload ATM2412B PDF144.0 X 104.0 X 10.0113.5 X 64.0 0.40 X 0.40 0.462 x 0.462 -20~+70RA69635.0V/3.3V
ATM2412BS
TFTDownload ATM2412BS PDF144.0 X 104.0 X 10.0113.5 X 64.0 0.40 X 0.40 0.462 x 0.462 -20~+70RA69635.0V/3.3V
AGM2412A
Download AGM2412A PDFDownload AGM2412A DRAWING144.0 X 104.0 X 12.5114.0 X 64.0 0.40 X 0.40 0.45 x 0.45 -20~+70T6963C5.0V/3.3V
AGM2412B
Download AGM2412B PDF170.0 x 101.7 x 14.0 for CFL BL132.0 x 76.0 0.47 x 0.47 0.50 x 0.50 -20~+70T6963C5.0V/3.3V
240 X 64 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
AGM2464B
Download AGM2464B PDFDownload AGM2464B DRAWING180.0 X 65.0 X 10.5 133.0 X 39.0 0.49 x 0.49 0.53 x 0.53 -20~+70T6963C5.0V/3.3V
AGM2464BD
Download AGM2464BD PDF180.0 X 65.0 X 15.0 133.0 X 39.0 0.49 x 0.49 0.53 x 0.53 -20~+70RA69635.0V/3.3V
320 X 240 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
ATM3224D
TFTDownload ATM3224D PDF160.0 X 109.0 X 11.6114.9 X 86.67 0.3528 X 0.3528 0.3528 x 0.3528 -20~+70RA88355.0V/3.3V
ATM3224E
TFTDownload ATM3224E PDF99.5 X 71.75 X 8.072.9 X 55.4 0.219 X 0.219 0.219 X 0.219 -20~+70RA88355.0V/3.3V
AGM3224C
Download AGM3224C PDFDownload AGM3224C DRAWING154.6 x 114.8 x 10.5 120.0 x 90.0 0.345 x 0.345 0.36 x 0.36 -20~+70-5.0V/3.3V
AGM3224D
TPDownload AGM3224D PDF167.1 x 109.0 x 11.0 for CCFL BL122.0 x 92.0 0.33 x 0.33 0.36 x 0.36 -20~+70-5.0V/3.3V
AGM3224V
CD,CGDownload AGM3224V PDF70.7 x 90.2 x 7.6 57.8 x 76.6 0.061 x 0.215 0.076 x 0.230 0~+50-3.0V
480 X 256 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
ATM4825A
TFTDownload ATM4825A PDF144.0 X 104.0 X 10.0113.5 X 64.0 0.231 X 0.231 0.231 X 0.231 -20~+70RA88355.0V/3.3V
480 X 320 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
AGM4832C
Download AGM4832C PDF156.0 x 94.9 x 11.5 119.2 x 80.8 0.228 x 0.228 0.24 x 0.24 -20~+70-3.3V
640 X 480 graphics LCD display module
Series PDFDrawingOutline Dimensions(mm)Viewing Area(mm)Dot Size(mm)Dot Pitch(mm)Operation Temperature (℃)Controller ICOperation Voltage
AGM6448F
Download AGM6448F PDF167.7 x 122.8 x 5.3 125.6 x 95.2 0.17 x 0.17 0.19 x 0.19 -20~+70-3.3V

BL: Backlight
LD: LED backlight unit
CL: CCFL backlight unit
NB: No backlight unit
WL: White LED backlight unit
CD: Color Display
TP: with Touch Panel
CG: COG Display
TFT: Monochrome TFT Display
